Stainless Steel 310S Valves

Stainless Steel 310S Check Valves, DIN 1983 SS 310S Ball Valves Dealer, ASME B16.34 SS 310S Gate Valves, Stainless Steel 310S Valves, Stainless Steel 310S Butterfly Valves Supplier in Mumbai, India.

SS 310S Valves

Also, the grade has a good mechanical property in it which makes it useful in extreme situations. Mechanical traits such as high tensile strength, great yield strength, and greater creep rupture properties and high hardness.

Industry details: Being one of the reputed names in the market, Champ Steels is one of the leading manufacturer, exporter and supplier of high quality Stainless Steel 310s Valves. The valves manufactured by them are from high quality of raw material which is procured from trusted market vendors in order to enhance the efficiency of the product. Some of the additional services offered by them are great performance, sleek design; High end finishing, accurate dimensions and timely delivery of the product are some of the services.

Stainless Steel 310S Diaphragm Valves, SS 310S Vane Valve, DIN 1.4845 Hygienic Ball Valves, Stainless Steel 1.4845 Trunnion Mounted Ball Valves, SS 310S Globe Valves Exporter, UNS S31008 Cryogenic Valves, 310S SS Plug Valve Manufacturer in Mumbai, India.

Their other services include the good packaging, quality material testing and relevant documents offered. The industry is engaged in offering their buyers relevant set of documents that will help them to counterpart the product along with the offered documents. Testaments such as fumigation certificate, QAP, certificate of origin, heat treatment chart, material tests certificates, material traceability record and packaging list that includes the net and the gross weight of the product are some of the documents offered.

Industry in order to provide their clients quality Stainless Steel 310s Valves, they conducts relevant material tests. These tests helps in ensuring the strict quality and efficiency of the product before finally delivering it to the clients. Tests such as flaring tests, micro and macro tests, pitting resistance tests, positive material identification tests, intergranular corrosion tests, and bend tests are some of the essential tests performed.


Equivalent Grades
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 310S 1.4845 S31008 SUS 310S 310S16 20Ch23N18 - X8CrNi25-21
Specification

Size : 1/2" to 72"

Temperature Rating : PTFE 450F,(232C)/ Grafoil 700 F(371C)

Working Pressure : Up to 6000 PSIG, valves are also available that can handle higher pressure

Pressure Rating : 150#,300#,600#,800#,1500#


Valve Type D&M Standard Connection End Operator
Gate Valve API 600,API 6D,API 603,API 602,API 6A,ASME B16.34,DIN1984,JIS2071 Flange, BW, SW, Thread Handwheel,Worm Gear,Pneumatic Actuator,Electric Actuator
Ball Vave API 6D,API 608,BS5351,ASME B16.34,DIN1983,JIS B2071 Flange, BW, SW, Thread Lever,Worm Gear,Pneumatic Actuator,Electric Actuator
Check Valve API 6D,API 594,BS 1868,ASME B16.34,DIN13709,JIS B2071 Flange, Wafer, Thread -
Globe Valve BS 1873,ASME B16.34,EN 588,DIN 3202,JIS 5752 Flange, BW, SW, Thread Handwheel,Worm Gear,Pneumatic Actuator,Electric Actuator
Butterfly Valve API 609,MSS SP-68,DIN593,JIS B2071 Flange, Lug, Wafer Handle,Worm Gear,Pneumatic Actuator,Electric Actuator
Operator Size Range
Handwheel 2” – 10” - Class 150, 300
2” – 6” - Class 600
Gear Operator 12” & Above - Class 150 & 300
8” & Above - Class 600
12” & Above - Class 900 & 1500
Types Of Stainless Steel Valves

SS 310S Valves

SS 310S Industrial Valves

Stainless Steel 310S Ball Valves | SS 310S Gate Valve | SS 310S Pulp Valves | Stainless Steel 310S Plug Valves | SS 310S Globe Valves | 310S SS Needle Valves | SS 310S Butterfly Valves | Stainless Steel 310S Manifold Valves | Stainless Steel 310S Diaphragm Valve | SS 310S Jacketed Valves Dealer | SS 310S Sight Glass - Flow Indicator Valves

SS 310S Valves

Stainless Steel 1.4845 Safety Relief Valve | SS S31008 Blow Down Valves | SS 1.4845 Forged Steel Valves Stockist | UNS S31008 Flush Bottom Valves | DIN 1.4845 Steel Check Valves | ANSI B16.10 SS Dual Plate Check Valves | SS S31008 Automatic Control Valves | SS 310S Pneumatic Control Valves | Stainless Steel 310S Non Return (NRV) Valves | SS 310S Single and Double Block Bleed Valves

Stainless Steel 310S Valves
Chemical Composition
Grade C Mn Si P S Cr Mo Ni Fe
SS 310S 0.08 max 2.0 max 1.00 max 0.045 max 0.030 max 24.00 - 26.00 0.75 max 19.00 - 21.00 53.095 min
Mechanical Properties
Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
7.9 g/cm3 1402 °C (2555 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 40 %
Application Industry

Application Industry
  • 1
    UNS S31008 Ball Valves

    used in Oil Refinery Industry

  • 2
    DIN 1.4845 Butterfly Valves

    used in General Piping Industry

  • 3
    SUS 310S Check Valves

    used in Gas Processing Industry

  • Chemical Industry
  • Oil & Gas Industry
  • Petrochemical Industry
  • Power Genration Industry
  • Sugar Industry
  • Food Processing Industry
  • Paper & Pulp Industry
  • Offshore and Onshore Services
